Get highly detailed construction-ready CAD and Revit drawings produced by dedicated drafting professionals who align with your standards, your tools, and your project deadlines from day one.
Supporting AEC Firms Across the USA
Architectural Drafting Services We Offer
Project-based support or a dedicated drafter embedded directly within your team.
Floor Plan Drafting
Detailed, dimensioned floor plans aligned with CAD & construction standards
Includes layouts, openings, annotations, and spatial clarity
Delivered in DWG, PDF, and Revit (on request)
Elevation Drawings
Exterior elevations showing façade design and vertical dimensions
Covers all sides with material callouts and level references
Coordinated with plans and sections for consistency
Section Drawings
Cross-sections illustrating internal construction and structural relationships
Includes wall assemblies, floor levels, and vertical circulation details
Cut at critical points for contractor clarity
Site Plan Drafting
Site layouts for planning approvals and permit submissions
Includes setbacks, boundaries, access roads, and utility layouts
Prepared to local authority standards
Construction Documentation
Complete drawing sets for permits, bidding, and construction execution
Covers plans, elevations, sections, details, and schedules
Structured for contractor and authority submission
Revit & BIM Drafting
Revit modeling and BIM documentation aligned to your standards
Includes family creation, sheet setup, and coordination workflows
Delivered in RVT and IFC formats
PDF / Sketch to CAD
Convert PDFs, hand sketches, or scans into clean CAD drawings
Fully layered, dimensionally accurate, and editable files
Ready for immediate use in design or documentation
As-Built Drawings
Accurate drawings reflecting real site conditions
Based on surveys, redlines, and on-site data
Used for renovation, compliance, and record documentation
Two Engagement Models. One Dedicated Team.
We offer two flexible engagement models built around how AEC firms actually work. Each year, we select the top 1% of architects and engineers from over 20,000 applications. After a month of structured training, they integrate into any AEC firm and deliver results from week one.
Dedicated Resource Model
A specialist architect or drafter joins your team directly — working inside your workflows, tools, and communication channels. Best for firms that need consistent, ongoing drafting capacity without the cost of a full-time hire.
Share your team structure, tools, and requirements. We identify the right specialist profile.
Pre-vetted drafters and architects selected for technical skill and team fit.
Integrated into your tools, CAD standards, and communication channels.
Adjust capacity based on workload — no hiring delays or fixed overhead.
Project-Based Model
A fixed-scope engagement for specific drawing sets or documentation packages. You define the deliverables, timeline, and format. Our team executes and delivers. Best for one-off projects or overflow drafting support.
Send sketches, PDFs, or CAD files. Scope and timeline confirmed within 24 hours.
Drawings produced as per your specifications and standards.
Senior architects verify accuracy, compliance, and completeness.
Receive DWG / RVT files with revisions included.
Not sure which model fits your firm? We'll recommend the right one on a free 30-minute call.
Start Your Drafting Project Today
Share your project details or discuss how a dedicated drafting professional can support your team. We respond within 24 hours.
Architectural Drafting Portfolio
Sample technical drawings and drafting work for residential and commercial projects.
Weddington Home
Why Architecture Firms Choose Us
Architecture and construction firms rely on us for high-quality drafting support and flexible engagement models that scale with project demand without the overhead of full-time hires.
Architecture Firms Are Losing Time to Drafting Overload
In-house design teams spend 40–60% of billable hours on documentation and construction drawings work that takes architects away from design, client management, and business development. Hiring additional drafters is slow, expensive, and creates fixed overhead that doesn't scale with project volume. Freelancers lack the systems and consistency for multi-drawing sets.
Dedicated Drafting Specialists, On Demand
Our drafters work as an integrated extension of your team aligned to your CAD standards, drawing conventions, and project timelines so your architects can focus on design.
Get Started TodayArchitects and CAD specialists with 11+ years across residential, commercial, and industrial projects.
Real Feedback, Real Results
Client stories that reveal how our Architectural Outsourcing Services cut costs by 50% and saved time with real-time revisions.
Industries & Sectors We Serve
Architectural drafting expertise across a wide range of project types and construction sectors.
Start Your Project With Confidence
Whether you need drafting support for a single project or a dedicated professional integrated directly into your team — our experts are ready to begin within days.
Discuss your project scope with a senior architect before committing.
Evaluate our team's quality and communication — no long-term contract required.
NDA signed before any files are shared. ISO-certified data security protocols.
Dedicated team onboarded within days. No bottlenecks, no delays.
DWG, RVT, IFC, PDF formatted to your firm's CAD standards and naming conventions.
Get a Free Consultation
Tell us about your project and we'll assign the right specialist.
Frequently Asked Questions
Yes. We assign dedicated drafting professionals exclusively to your projects, ensuring consistency in standards, workflows, and design language — functioning as a seamless extension of your in-house team for as long as needed.
Yes. We offer a 30-day risk-free trial on a live BIM or drafting task of your choice. This allows you to evaluate our quality, coordination, and delivery standards in a real project environment. If the outcome doesn't meet your expectations, you can request a full refund. All deliverables remain your property.
Absolutely. We align working hours to your time zone, ensuring real-time availability during your core business hours for daily check-ins, live coordination calls, and urgent revisions — regardless of your location globally.
We offer three models: a dedicated monthly retainer for ongoing workloads, a project-based engagement for defined deliverables, and an hourly on-demand model for flexible, as-needed support — each backed by a clear Service Level Agreement.
Every drawing undergoes a three-tier review — drafter self-check, senior peer review, and project lead QA — before delivery. We use standardized checklists, version control, and document all client feedback for continuous improvement throughout the engagement.
Yes. We use encrypted file transfers, signed NDAs, and restrict data access to assigned team members only. Our workflows align with ISO 9001, AIA CAD Layer Guidelines, BS 1192, and BIM Execution Plan protocols.
You'll have a single dedicated Project Manager as your named point of contact handling briefings, revisions, deadlines, and coordination. For technical queries, your lead drafter is also directly accessible when needed.
We typically onboard and begin work within 48–72 business hours after agreement. Urgent projects can be mobilized same-day. Larger dedicated-team engagements may require up to one week for proper allocation and briefing.
Our team has delivered residential, commercial, hospitality, healthcare, educational, and industrial projects — producing schematic sets, full CD packages, permit drawings, shop drawings, as-builts, and BIM models using AutoCAD, Revit, ArchiCAD, and SketchUp.
Have more questions about our architectural drafting services?
Talk to Us
